1624390000
1624390000
- Available: 0
- Manufacturer: Weidmüller
- Part Number: 1624390000
- Detailed Description:4 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.300" (7.62mm) 90°, Right Angle Through Hole
- Category:Connectors, Interconnects | Terminal Blocks - Headers, Plugs and Sockets
- RoHS Status： ROHS Compliant
- Datasheet: Datasheet
Reference Price (USD)
1+
0.0000
10+
0.0000
100+
0.0000
1000+
0.0000
10000+
0.0000
Considering price fluctuations, this price is only for reference. Please send RFQ to info@aceera.net to get the best price, thank you.
| Manufacturer | Weidmüller |
|---|---|
| Series | Omnimate SL |
| Package | Bulk |
| Standard Package | 100 |
| Product Status | Obsolete |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Number of Positions | 4 |
| Positions Per Level | 4 |
| Number of Levels | 1 |
| Pitch | 0.300" (7.62mm) |
| Header Orientation | 90°, Right Angle |
| Plug Wire Entry | - |
| Termination Style | Solder |
| Mounting Type | Through Hole |
| Current - IEC | 18.5A |
| Voltage - IEC | 800 V |
| Current - UL | 15 A |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Color | Orange |
| Operating Temperature | -50°C ~ 100°C |
| Contact Mating Finish | Tin |
| Features | - |
| Material Flammability Rating | UL94 V-0 |
| Ingress Protection | - |
| Screw Size | - |
| Torque - Screw | - |
| Wire Strip Length | - |
| Contact Material | Copper Alloy |
| Housing Material | Polybutylene Terephthalate (PBT) |
| Contact Tail Length | 0.126" (3.20mm) |
| Insulation Height | 0.335" (8.51mm) |
| RoHS Status | RoHS Compliant |
|---|---|
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8536.69.4040 |
